2.4GHz max 23dBm & 5GHz max 20dBm output power
IEEE 802.11ac / ax compliant & backward compatible with 802.11ax/ac/a/b/g/n
2×2 2.4G & 2×2 5G MIMO Technology, up to 1.8Gbps Mini PCI Express edge connector
SupporttheFrequency2412MHz~2482MHz
SupporttheFrequency5180MHz~5825MHz
RoHS compliance ensure a high level protection of human health and the environment from risks that can be posed by chemicals
Supports Spatial Multiplexing,Cyclic-Delay Diversity (CDD), Low-Density Parity Check (LDPC) Codes,Maximal Ratio Combining (MRC), Space Time Block Code (STBC)
Supports IEEE 802.11d, e, h, i, k, r, v time stamp, and w standards
Supports Dynamic Frequency Selection (DFS)
CardsareindividuallycalibratedforQualityAssurance
Product Description
DR 7915 based on MT7915 + MT7975 Chipset is an enterprise wireless module integrated with 2x2 2.4G high power Radio module and 2x2 5G high power Radio module designed
specifically to provide users with mobile access to high-bandwidth video streaming, voice, and data transmission for office and challenging RF environment infactories, warehousese stablishment.
Specifications
Symbol
Parameter
Chipset
MT7915+MT7975
Host Interface
Mini PCI Express 2.1
Antenna Connector
2 x UF.L
Frequency Range
2.4GHz: 2.412GHz to 2.472GHz
5GHz: 5.180GHz to 5.825GHz
Operating Voltage
3.3V DC
Power Consumption
TBD
Modulation Techniques
OFDM: BPSK, QPSK, DBPSK, DQPSK, 16-QAM, 64-QAM, 256-QAM
Environmental Temperature
Operating: -40°C to 70°C, Storage: -40°C to 90°C
Environmental Humidity, non-condensing
Operating: 5% to 95%, Storage: Max. 90%
ROHS Compliance
YES
Dimensions (W×H×D)
51mm × 30mm × 5.8mm
RF Performance Table
Operating Mode
Data Rate
TX Power
Tolerance
1 Chain
2 Chains
2.4 GHz
802.11b
11Mbps
20dBm
23dBm
±2dB
2.4 GHz
802.11g
54Mbps
17dBm
20dBm
±2dB
2.4 GHz
802.11n HT20
MCS7
17dBm
20dBm
±2dB
2.4 GHz
802.11n HT40
MCS7
14dBm
17dBm
±2dB
